SY-M 10KN Digital Pull Off Adhesion Tester 0.001KN / 0.001MPa Resolution

Name: SYM 10KN Digital Pull Off Adhesion Tester 0001KN 0001MPa Resolution
Brand: SAMYON
Price: 1 USD

China SY-M 10KN Digital Pull Off Adhesion Tester 0.001KN / 0.001MPa Resolution wholesale

Brand Name : SAMYON

Model Number : SY-M

Certification : ISO

Place of Origin : CN

MOQ : 1

Price : Can be negotiated

Payment Terms : Western Union, MoneyGram, , T/T, D/P, D/A

Supply Ability : 100sets per week

Delivery Time : 3-5days

Packaging Details : Carton

Name : Pull-off strength tester

Standard : ISO 4624

Test range : 0-10KN

Pull-off Pressure : 0-127.38MPa

Resolution : 0.001KN/0.001MPa

Stroke : 10mm

Contact Now

SY-M 10KN Digital Pull Off Adhesion Tester With Four Different Sizes Dolly

SY-M 10KN Digital Pull-off Adhesion Tester

Application:

It is used to test the pull-off adhesion strength of the coating on steel surface, concrete surface or other material’s surface.

Standard:

ISO 4624 Paints and varnishes - Pull-off test for adhesion

ASTM D 4541 Standard Test Method for Pull-Off Strength of Coatings Using Portable Adhesion Testers

ASTM D7234 Standard Test Method for Pull-Off Adhesion Strength of Coatings on Concrete Using Portable Pull-Off Adhesion Testers

GB/T 5210-2006 Paints and varnishes – pull-off test for adhesion

Parameters:

Item	Name	Details
1	Test range	0-10KN
2	Dolly Size	20mm (Standard); 10mm/14mm/50mm(Optional)
3	Max. Pull-off Pressure (φ10mm dolly)	0-127.38MPa
4	Max. Pull-off Pressure (φ14mm dolly)	0 - 64.99MPa
5	Max. Pull-off Pressure (φ20mm dolly)	0-31.84MPa
6	Max. Pull-off Pressure (φ50mm dolly)	0-5.09MPa
7	Resolution	0.001KN/0.001MPa
8	Stroke	10mm
9	Power	Li battery

Features:

1. Portable design, can be used anywhere.

2. Built-in rechargeable lithium battery, no need any external power source.

3. Selectable directly four different sizes dolly(20mm/10mm/14mm/50mm) for different resolution and testing range

4. Get the testing results from LCD directly.

5. Includes all tools needed for testing

6. High-precise professional sensor ensures 0.001MPa resolution

7. Self-aligning dollies ensure to get a reliable testing results for smooth or uneven surfaces.

8. Two units(MPa and psi) for selection and can be converted automatically.

9. Showing pull-off rate allows users monitor and adjust pull speed according to different test requirements.

SY-M 10KN Digital Pull Off Adhesion Tester 0.001KN / 0.001MPa Resolution
